MUST off grid inverter with mppt 2kw 3kw 4kw 5kw lcd battery backup on grid link inverter 272*355*100 mm / 297.5*468*125 mm

1 Piece
MOQ
$450.00(1 - 299 Pieces) $189.00(>=300 Pieces)
prezzo
MUST off grid inverter with mppt 2kw 3kw 4kw 5kw lcd battery backup on grid link inverter 272*355*100 mm / 297.5*468*125 mm
Caratteristiche Galleria Descrizione di prodotto Richieda una citazione
Caratteristiche
Specificazioni
Customized support: Software reengineering
Model Number: PH1800 Plus
Type: DC/AC Inverters
Output Type: Single
Output Current: 30A-75A
Output Frequency: 50Hz/60Hz
Size: 272*355*100 mm/297.5*468*125 mm
Weight: 7.4-14KG
Certificate: CE
Item: PH1800 Plus Hybrid Solar Charge Controller Inverter 1.5KW 24V DC
Waveform: Pure sine wave solar inverter
Display: LCD+LED
Transfer Time: 10ms
Inverter Efficiency: >93% Solar Inverter
Color: White
Communication Interface: RS485,USB
Built-in: MPPT 80A
Rated Power: 2000w~5000w
Compatible: Generator
Informazioni di base
Certificazione: CE
Model Number: PH1800 Plus
Termini di pagamento e spedizione
Descrizione di prodotto

Must PH1800 Plus Series High Frequency On/Off Grid Hybrid Solar Inverter 2kw 3kw 4kw 5kw 5.5kw solar inverter

hybrid solar inverter

high frequency hybrid solar inverter

must solar inverter

MODEL PH18-2024 Plus PH18-3024 Plus PH18-3048 Plus PH18-4048 Plus PH18-5048 Plus PH18-5548 Plus
Nominal Battery System Voltage 24VDC 48VDC
INVERTER OUTPUT
Rated Power 2000W 3000W 3000W 4000W 5000W 5500W
Surge Power 4000W 6000W 6000W 8000W 10000W 11000W
Waveform Pure Sine Wave
AC Voltage Regulation (Batt.Mode) 220VAC-240VAC(setting)
Electric Current 8.7A 13A 17.4A 21.7A 23.9A
Inverter Efficiency(Peak) 93%
Transfer Time 10ms(For for Personal Computers) 20ms( For Other Home Appliance)
AC INPUT
Voltage 230VAC
Selectable Voltage Range 170-280VAC(For Personal Computers),90-280VAC(For Home Appliances),184-253VAC(VDE4105)
Frequency Range 50Hz/60Hz (Auto Sensing)
BATTERY
Normal Voltage 24VDC 48VDC
Floating Charge Voltage 27.4VDC 54.8VDC
Overcharge Protection 31VDC 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 145VDC
PV Array MPPT Voltage Range 30-130VDC 64-130VDC
Standby Power Consumption 2W
PV Array MPPT Voltage Range 2000W 4000W
Maximum PV Array 80A
Maximum Efficiency 98%
Maximum AC Charge Current 60A
Maximum Charge Current 140A
MECHANICAL SPECIFICATIONS
Machine Dimensions (W*H*D) 272*355*100 mm 297.5*468*125 mm
Net Weight(Kg) 7.4 14
Package Dimensions(W*H*D) 485*393*251 638*395*241
Gross Weight(Kg) 9.5 16.4
OTHER
Humidity 5% to 95% Relative Humidity (Non-condensing)
Operating Temperature 0°C-55°C
Storage Temperature -15°C-60°C
*Products specifications are subject to change without further notice
Product Description

Packaging & Shipping

FAQ

Q1: How to choose a right inverter?
A1:Tell us your demand, then our sales will recommend a suitable inverter to you.

Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.

Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.

Q4: What is the warranty of inverter?
A4: One year warranty on Must-Solar product.

Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.

Interested? Why not send our "inquiry" for more details?
